Siemens
GPC131.1P Damper Actuator, SR Rotary, 35 lb-in
GPC131.1P Damper Actuator, SR Rotary, 35 lb-in
SKU:GPC131.1P
Low stock: 5 left
Regular price
RM1,598.00
Regular price
Sale price
RM1,598.00
Unit price
/
per
Shipping calculated at checkout.
Control Type: On/Off
Couldn't load pickup availability
GPC Series Electric Damper Actuator, spring return, 35 lb-in. For use on economizer dampers and small control dampers
Technical Specifications:
| Actuator Type |
Spring return
|
|
Actuation Style
|
Rotary
|
|
Control or Fire/Smoke Type
|
Control Damper
|
|
Plenum or Standard Rating
|
Plenum
|
|
Torque
|
35 lb-in
|
|
Fail Safe
|
Yes
|
|
Control Signal
|
Floating control
|
|
Positioning time
|
Runtime for 90° 60 s
|
|
Position feedback
|
No
|
|
Power consumption
|
Running: 3.5 VA (2.1 W), Holding: 2.8 VA (1.7 W)
|
|
Ambient temperature, operation
|
-25 to 130 °F, -32 to 55 °C
|
|
Angular rotation
|
90°
|
|
Operating voltage
|
24 VAC, 24 VDC
|
|
Supply Voltage
|
24 VAC/DC
|
|
Frequency
|
50/60 Hz
|
|
Auxiliary Switch
|
No
|
|
Cable length
|
3 ft
|
|
Dimensions (W x H x D)
|
2.83 x 5.61 x 2.48 in
|
|
Material, housing
|
NEMA 1, Plenum rated rugged plastic
|
