Non-spring return Damper Actuator, 10 Nm, SmartAct

• Direct-coupled actuators for air dampers, ventilation flaps, louvers and VAV-units.
• Protection class: IP54
• End switch function/capacity: SPDT switch 230 V, 5(3) A for models with end switch
• Shaft mounting: for round shafts 8..16 mm; square shafts 6..13 mm
• Removable wiring box for direct wiring to and from controller
• Rotation direction selectable by switch
• Adjustable mechanical end limits included
• 24 VAC models are also suitable for 24 VDC
• Spring return: no
• Built-in rotation limiter: yes
• Manual operation: yes

• Power supply: 230Vac
• Control input signal: 2-pt
• End switches: no
• Position feedback: no
• Runtime: max. 140s
• Torque: 10Nm
• Damper area: 2m2

Documentations:

Technical data sheet - CN4610A1001
