Siemens
Compact, configurable room automation station and actuator combination, BACnet/IP, 24 V, 2 UI, 1 AO, 4 triac, pressure sensor, FPB052
Compact, configurable room automation station and actuator combination, BACnet/IP, 24 V, 2 UI, 1 AO, 4 triac, pressure sensor, FPB052
SKU:DXR1.E09PDZ-113
Low stock: 1 left
Regular price
RM1,680.00
Regular price
Sale price
RM1,680.00
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
- Compact, configurable room automation station in combination with actuator for HVAC
- BACnet IP communications (BTL certified)
- 2-port Ethernet switch
- USB interface
- Operating voltage AC 24 V
- Built-in 5 Nm actuator
- Internal 0…500 Pa differential pressure sensor
- Plug-in terminal blocks
Technical Specifications:
| Operating voltage |
AC 19.2…28.8 V, 24 V
|
|
Frequency
|
50/60 Hz
|
|
Power consumption
|
Max. 7.5 VA
|
|
Communication
|
BACnet IP
|
|
Max. cable length
|
30 m
|
|
Digital outputs, number
|
4
|
|
Analog outputs, number
|
1
|
|
Mounting
|
Directly on the damper shaft
|
|
Degree of protection
|
IP20
|
|
Dimensions (W x H x D)
|
143.1 x 83.6 x 137 mm
|
Documentation:
