Siemens

GDB181.1E/BA VAV compact controller BACnet, AC 24 V, 5 Nm, 150 s, 300 Pa

GDB181.1E/BA VAV compact controller BACnet, AC 24 V, 5 Nm, 150 s, 300 Pa

GDB181.1E/BA

Low stock: 2 left

RM2,122.00
RM2,122.00
Sold out
Shipping calculated at checkout.

Voltage AC/DC
Torque
Type
  • Networked compact controller with BACnet MS/TP (BTL-listed) communication for plants with variable or constant air volume flow
  • Integrated, highly precise differential pressure sensor, damper actuator and digitally configurable air volume controller
  • Nominal torque 5 Nm, air damper rotation angle mechanically adjustable between 0 and 90°
  • Configurable as single device per room or for cascade control with pressure ratio 1:1, positive pressure, or negative pressure
  • Prewired with a 0.9 m connecting cable and a 0.9 m bus cable



Technical Specifications:

Torque
5 Nm
Air damper area
0.8 m²
Angular rotation
90°
Power consumption
3 VA, 2.5 W
Positioning time
150 s
Communication
BACnet MS/TP
Cable length
0.9 m
Degree of protection
IP54
Ambient temperature, operation
0…50 °C
Medium temperature
0…50 °C
Dimensions (W x H x D)
71 x 158 x 61 mm
Operating voltage
AC 24 V

Documentations:
