Siemens
GIB336.1E Rotary air damper actuator, AC 230 V, 3-position, 35 Nm, 150 s, 2 auxiliary switches
GIB336.1E Rotary air damper actuator, AC 230 V, 3-position, 35 Nm, 150 s, 2 auxiliary switches
SKU:GIB336.1E
In stock
Regular price
RM1,680.00
Regular price
Sale price
RM1,680.00
Unit price
/
per
Shipping calculated at checkout.
Control Type: On/Off
Couldn't load pickup availability
- With self-centering shaft adapter for shaft dia. 8..25.6 mm, square 6...18 mm, min. shaft length 20 mm
- With position indication and adjustable mechanical limit stop
- Button for disengaging the gear train to enable manual override
- With housing made of die-cast aluminium and 0.9 m connecting cable
Specifications:
| Torque |
35 Nm
|
|
Air damper area
|
6 m²
|
|
Angular rotation
|
90°
|
|
Power consumption
|
5 VA, 5 W
|
|
Positioning time
|
150 s
|
|
Cable length
|
0.9 m
|
|
Positioning signal
|
3-position
|
| Spring return function | No |
|
Degree of protection
|
IP54
|
|
Ambient temperature, operation
|
-32…55 °C
|
|
Medium temperature
|
-32…55 °C
|
|
Ambient humidity, operation
|
5…95 % r.h.
|
|
Dimensions (W x H x D)
|
71 x 313 x 100 mm
|
|
Operating voltage
|
AC 230 V
|
|
Position feedback
|
None
|
|
Auxiliary switch
|
2
|
