Siemens
GLB181.1E/3 VAV compact controller, AC 24 V, DC 0...10 V, 10 Nm, 150 s, 300 Pa
GLB181.1E/3 VAV compact controller, AC 24 V, DC 0...10 V, 10 Nm, 150 s, 300 Pa
SKU:GLB181.1E/3
Low stock: 2 left
Regular price
RM2,034.00
Regular price
Sale price
RM2,034.00
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
- Compact controller for plants with variable or constant air volume flow
- Integrated, highly precise differential pressure sensor, damper actuator and digitally configurable air volume controller
- Nominal torque 10 Nm, air damper rotation angle mechanically adjustable between 0 and 90°
- Forced close-off function in DC 2...10 V operation
- Optionally configurable as VAV compact controller or as damper actuator/differential pressure sensor unit
- Prewired with a 0.9 m connecting cable
Technical Specifications:
| Torque |
10 Nm
|
|
Air damper area
|
1.5 m²
|
|
Angular rotation
|
90°
|
|
Power consumption
|
3 VA, 2.5 W
|
|
Positioning time
|
150 s
|
|
Cable length
|
0.9 m
|
| Positioning signal | DC 0...10 V, DC 2…10 V, 3-position |
|
Degree of protection
|
IP54
|
|
Ambient temperature, operation
|
0…50 °C
|
|
Medium temperature
|
0…50 °C
|
| Ambient humidity, operation | 95 % r.h. |
|
Dimensions (W x H x D)
|
71 x 158 x 61 mm
|
|
Operating voltage
|
AC 24 V
|
| Position feedback | DC 0…10 V |
| Auxiliary switch | 0 |
