Siemens
GLB346.1E Rotary air damper actuator, AC 230 V, 2-position/3-position, 10 Nm, 150 s, 2 auxiliary switches
GLB346.1E Rotary air damper actuator, AC 230 V, 2-position/3-position, 10 Nm, 150 s, 2 auxiliary switches
SKU:GLB346.1E
In stock
Regular price
RM838.00
Regular price
Sale price
RM838.00
Unit price
/
per
Shipping calculated at checkout.
Control Type: On/Off
Couldn't load pickup availability
- For shaft dia. 8..16 mm, square 6...12 mm, min. shaft length 30 mm
- With position indication and adjustable mechanical limit stop
- Button for disengaging the gear train to enable manual override
- With base made of steel, plastic housing and 0.9 m connecting cable
Specification
| Torque | 10 Nm |
| Air damper area | 1.5 m² |
| Angular rotation | 90° |
| Power consumption | 5.8 VA, 1.9 W |
| Positioning time | 150 s |
| Cable length | 0.9 m |
| Spring return function | Yes |
| Positioning signal | 2-position/3-position |
| Degree of protection | IP54 |
| Ambient temperature, operation | -32…55 °C |
| Dimensions (W x H x D) | 68 x 137 x 59.5 mm |
| Operating voltage | AC 230 V |
| Position feedback | None |
| Auxiliary switch | 2 |
