Siemens
GQD321.1A Damper actuator, rotary, 2 Nm, IP40, AC 230 V, 2-position, 30/15 s, spring return
GQD321.1A Damper actuator, rotary, 2 Nm, IP40, AC 230 V, 2-position, 30/15 s, spring return
SKU:GQD321.1A
In stock
Regular price
RM758.00
Regular price
Sale price
RM758.00
Unit price
/
per
Shipping calculated at checkout.
Control Type: On/Off
Couldn't load pickup availability
- For shaft dia 8...15 mm, square 6...11 mm, min. shaft length 20 mm
- With housing made of plastic and 0.9 m connecting cable
Specifications:
| Torque |
2 Nm
|
|
Air damper area
|
0.3 m²
|
|
Angular rotation
|
90°
|
|
Power consumption
|
10 VA, 4.5 W
|
|
Positioning time
|
Open:30 s, Close:15 s
|
|
Cable length
|
0.9 m
|
|
Positioning signal
|
2-position
|
|
Degree of protection
|
IP40
|
|
Ambient temperature, operation
|
-32…55 °C
|
|
Medium temperature
|
-32…55 °C
|
|
Ambient humidity, operation
|
5…95 % r.h.
|
|
Dimensions (W x H x D)
|
73 x 122 x 63 mm
|
|
Operating voltage
|
AC 230 V
|
|
Position feedback
|
None
|
|
Auxiliary switch
|
0
|
