Siemens
GQD326.1A Damper actuator, rotary, 2 Nm, IP40, AC 230 V, 2-position, 30/15 s, spring return, 2x aux switches
GQD326.1A Damper actuator, rotary, 2 Nm, IP40, AC 230 V, 2-position, 30/15 s, spring return, 2x aux switches
SKU:GQD326.1A
In stock
Regular price
RM882.00
Regular price
Sale price
RM882.00
Unit price
/
per
Shipping calculated at checkout.
Control Type: On/Off
Couldn't load pickup availability
- For shaft dia 8...15 mm, square 6...11 mm, min. shaft length 20 mm
- With housing made of plastic and 0.9 m connecting cable
Specification
| Torque | 2 Nm |
| Air damper area | 0.3 m² |
| Angular rotation | 90° |
| Power consumption | 10 VA, 4.5 W |
| Positioning time | Open:30 s, Close:15 s |
| Cable length | 0.9 m |
| Positioning signal | 2-position |
| Degree of protection | IP40 |
| Ambient temperature, operation | -32…55 °C |
| Medium temperature | -32…55 °C |
| Ambient humidity, operation | 95 % r.h. |
| Dimensions (W x H x D) | 73 x 122 x 63 mm |
| Operating voltage | AC 230 V |
| Position feedback | None |
| Auxiliary switch | 2 |
