Siemens
GRD326.1U 30lb-in,SR,2PT,230V,SW,FS
GRD326.1U 30lb-in,SR,2PT,230V,SW,FS
SKU:GRD326.1U
Low stock: 5 left
Regular price
RM1,424.00
Regular price
Sale price
RM1,424.00
Unit price
/
per
Shipping calculated at checkout.
Control Type: On/Off
Couldn't load pickup availability
GRD326.1U 30 lb-in, Spring Return, 2-Position, 230V, Switches, Fire-Smoke
Specification
| Actuator Type |
Electronic Fire and Smoke
|
|
Actuation Style
|
Rotary
|
|
Control or Fire/Smoke Type
|
Fire/Smoke Control Damper
|
|
Electronic Fusible Link (EFL)
|
YES
|
|
Plenum or Standard Rating
|
Standard
|
|
Torque
|
30 lb-in
|
|
Fail Safe
|
Yes
|
|
Spring return function
|
Spring return function
|
|
Control Signal
|
2-position
|
|
Positioning time
|
Operating: 30 s runtime for 90 °; Closing (power loss with spring return: 15 s max
|
|
Power consumption
|
Running: ~12 VA, Holding: ~4 VA
|
|
Ambient temperature, operation
|
-18…60 °C; 0…140 ºF
|
|
Ambient humidity, operation
|
Maximum 95% rh non-condensing
|
|
Angular rotation
|
95°
|
|
Supply Voltage
|
230 VAC
|
|
Frequency
|
50/60 Hz
|
|
Auxiliary switch
|
YES
|
|
Cable length
|
3 ft
|
|
Dimensions (W x H x D)
|
3.5 x 8.5 x 3 in
|
|
Material, housing
|
NEMA 1, plenum-rated plastic
|
| Degree of protection | IP40 |
|
Standard
|
UL60730; cUL CSA 60730; CE conformity for Residential, Commercial, and Industrial environments
|
