Siemens
GSD161.1A Rotary air damper actuators, AC/DC 24 V, 2 Nm, 30 s
GSD161.1A Rotary air damper actuators, AC/DC 24 V, 2 Nm, 30 s
SKU:GSD161.1A
In stock
Regular price
RM882.00
Regular price
Sale price
RM882.00
Unit price
/
per
Shipping calculated at checkout.
Control Type: Modulating (Electrical)
Couldn't load pickup availability
- Operate direct driven zone dampers used to control air flow in ducts specifically to address modulating controllers domestic and light commercial barrel damper applications.
- For shaft dia 8...15 mm, square 6...11 mm, min. shaft length 20 mm
- With housing made of plastic and 0.9 m connecting cable
Specification
| Torque | 2 Nm |
| Air damper area | 0.3 m² |
| Angular rotation | 90° |
| Power consumption | 2.4 VA, 1.4 W |
| Positioning time | 30 s |
| Cable length | 0.9 m |
| Positioning signal | DC 0/2..10 V |
| Degree of protection | IP54 |
| Ambient temperature, operation | -32…55 °C |
| Medium temperature | None |
| Dimensions (W x H x D) | 73 x 122 x 63 mm |
| Operating voltage | AC 24 V, DC 24…48 V |
| Auxiliary switch | 0 |
