Siemens
GSD341.1A Rotary air damper actuators, AC 240 V, 2 Nm, 30 s
GSD341.1A Rotary air damper actuators, AC 240 V, 2 Nm, 30 s
SKU:GSD341.1A
In stock
Regular price
RM596.00
Regular price
Sale price
RM596.00
Unit price
/
per
Shipping calculated at checkout.
Control Type: On/Off
Couldn't load pickup availability
- Operate direct driven zone dampers used to control air flow in ducts specifically to address two or three-position domestic and light commercial barrel damper applications.
- For shaft dia 8...15 mm, square 6...11 mm, min. shaft length 20 mm
- With housing made of plastic and 0.9 m connecting cable
Technical Specification
| Torque |
2 Nm
|
|
Air damper area
|
0.3 m²
|
|
Angular rotation
|
90°
|
|
Power consumption
|
4.5 VA, 1.8 W
|
|
Positioning time
|
30 s
|
|
Cable length
|
0.9 m
|
|
Positioning signal
|
Open-close / three-position
|
|
Degree of protection
|
IP54
|
|
Ambient temperature, operation
|
-32…55 °C
|
|
Dimensions (W x H x D)
|
73 x 122 x 63 mm
|
|
Operating voltage
|
AC 100…240 V
|
|
Auxiliary switch
|
0
|
