Siemens
GSD346.1A Rotary air damper actuators, AC 240 V, 2 Nm, 30 s, 2 auxiliary switches
GSD346.1A Rotary air damper actuators, AC 240 V, 2 Nm, 30 s, 2 auxiliary switches
SKU:GSD346.1A
In stock
Regular price
RM736.00
Regular price
Sale price
RM736.00
Unit price
/
per
Shipping calculated at checkout.
Control Type: On/Off
Couldn't load pickup availability
- Operate direct driven zone dampers used to control air flow in ducts specifically to address two or three-position domestic and light commercial barrel damper applications.
- For shaft dia 8...15 mm, square 6...11 mm, min. shaft length 20 mm
- With housing made of plastic and 0.9 m connecting cable
Specification
| Torque | 2 Nm |
| Air damper area | 0.3 m² |
| Angular rotation | 90° |
| Power consumption | 4.5 VA, 1.8 W |
| Positioning time | 30 s |
| Cable length | 0.9 m |
| Positioning signal | Open-close / three-position |
| Degree of protection | IP54 |
| Ambient temperature, operation | -32…55 °C |
| Dimensions (W x H x D) | 73 x 122 x 63 mm |
| Operating voltage | AC 100…240 V |
| Auxiliary switch | 2 |
