Siemens
GVD321.1U 200 lb-in,SR,2PT,230V,FS
GVD321.1U 200 lb-in,SR,2PT,230V,FS
SKU:GVD321.1U
Low stock: 5 left
Regular price
RM1,822.00
Regular price
Sale price
RM1,822.00
Unit price
/
per
Shipping calculated at checkout.
Control Type: On/Off
Couldn't load pickup availability
Fire and Smoke Damper Actuator 200 lb-in 2-position control , Spring Return, 230 VAC compatible with built in Electronic Fuse Link capability. For use on UL-listed smoke control dampers and combination fire/smoke rated dampers. Designed to meet UL555S.
Specification
| Actuator Type |
Electronic Fire and Smoke
|
|
Actuation Style
|
Rotary
|
|
Control or Fire/Smoke Type
|
Fire/Smoke Control Damper
|
|
Electronic Fusible Link (EFL)
|
YES
|
|
Plenum or Standard Rating
|
Standard
|
|
Torque
|
200 lb-in
|
|
Fail Safe
|
Yes
|
|
Spring return function
|
Spring return function
|
|
Control Signal
|
2-position
|
|
Positioning time
|
Run time for 90° 30s nominal, Spring return 15 s max
|
|
Power consumption
|
35 VA / 9 VA, Run / Hold
|
|
Ambient temperature, operation
|
0…140 ºF
|
|
Ambient humidity, operation
|
95 % r.h
|
|
Angular rotation
|
95°
|
|
Supply Voltage
|
230 VAC
|
|
Frequency
|
50/60
|
|
Auxiliary switch
|
0
|
|
Cable length
|
3 ft
|
|
Dimensions (W x H x D)
|
3.8 x 10.75 x 3.4 in
|
|
Material, housing
|
NEMA 1 / IP40, plenum-rated plastic, high temperature polymer
|
|
Standard
|
UL60730; cUL CSA 60730; CE conformity for Residential, Commercial, and Industrial environments
|
