Belimo
Rotary actuator fail-safe, 10 Nm, AC 24...240 V / DC 24...125 V, Open/close, 75 s, 2 x SPDT, IP54
Rotary actuator fail-safe, 10 Nm, AC 24...240 V / DC 24...125 V, Open/close, 75 s, 2 x SPDT, IP54
SKU:NFA-S2
In stock
Regular price
RM1,598.00
Regular price
Sale price
RM1,598.00
Unit price
/
per
Shipping calculated at checkout.
Control Type: On/Off
Couldn't load pickup availability
Specifications:
Angle of rotation | 95 |
Auxiliary switches | 2 x SPDT |
Control type | Open/close |
Degree of protection | IP54 |
Direction of rotation (fail-safe) | Selectable by mounting L/R |
Electrical connection | Cable |
Fail-safe function | Fail-safe |
Manual override | By means of hand crank and locking switch |
Mechanical interface | Universal shaft clamp 10...25.4 mm |
Power consumption (holding) | 2.5 W |
Power consumption (running) | 6 W |
Running time (fail-safe) | <20 s |
Running time (motor) | 75 s / 90° |
Torque | 10 Nm |
Voltage AC/DC | AC 24...240 V / DC 24...125 V |
Documentation:
