Vector Controls

SCC-C1 Smart CO2 transmitter surface mount

SCC-C1 Smart CO2 transmitter surface mount

SKU:SCC-P2

Low stock: 5 left

Regular price RM1,746.00
Regular price Sale price RM1,746.00
Sold out
Shipping calculated at checkout.

Item Name (Item Code)
The CO2 concentration is measured through non-dispersive infrared (NDIR) waveguide technology with ABC automatic background calibration algorithm. The applied measuring technology guarantees excellent reliability and long term stability. The microprocessor samples the CO2 once per second. It calculates an averaging signal over a preset number of seconds and generates the output signal.

Standard signal ranges are 0-10 VDC, 2-10 VDC, 4-20 mA and 0-20 mA. Other ranges can be defined by using the external display and programming module OPA-S.

Applications

  • Demand based ventilation for homes and offices based on measurement of the CO2 concentration
  • Preset standard measuring range 0...2000 ppm, max possible range 0...5000 ppm
  • Recording of minimum and maximum limits for critical environments
  • Direct ventilation control of extraction fan
  • Air measurement
  • Zone control

            Features Specifications:

            • CO2 measurement over external probes (for air ducts, …)
            • Minimum and maximum value memory
            • 0...10 V, 0...20 mA or 2...10 V. 4...20 mA measuring signals selectable with jumpers
            • Optional alternative signal ranges programmable
            • May be used as simple P-controller
            • Selectable averaging signal
            • Optional external display (OPA-S)
            • Status LED



              Item name
              Item code Description
              SCC-C1 40-300249 CO2 transmitter with tube connectors for external air probe



              Documentations:

              Operation Manual - SCC-C1

              Install Sheet - SCC-C1
