SCC2-CQ Controller and Sensor (X2 OS) for CO2 and Air Quality

The SCC2 is a programmable controller and sensor with communication capabilities. Each control loop may use 2 PI sequences and 2 binary stages. The SCC2 comes with a built in RS485 communication interface that allows peer to peer communication with an operation terminal such as OPT1-(2TH)-VC.

Communication plug-in allow for integration of the controller into a network. These modules are described in their own manual. Currently available are plug-ins for BACnet and MODBUS.

Flexible application configuration is made with a parameter-setting routine using the standard operation terminal.

Complete parameter sets may be copied by use of an accessory called AEC-PM2 or exchanged with a PC using an RS485-USB converter and the EasySet program.

Applications

• Ventilation control
• Air measurement
• Zone control
• VAV control

Features Specifications:

• Two universally configurable control loops:
• Functions for dehumidifying, set point shift and cascade control
• Multiple auxiliary functions: heat-cool auto changeover, automatic enable, set point compensation
• Free heating and cooling with economizer function based on enthalpy or temperature
• Differential, averaging, min and max functions, enthalpy and dew point calculations
• Transmitter function for inputs and set points
• Universal analog outputs (VDC, mA) and one relay with a normally open and a normally closed contact (SPDT)
• 8 freely assigned alarm conditions, selectable state of outputs on alarm condition
• Password protected programmable user and control parameters
• Measures CO2 and VOC
