Siemens

SQL321B25 Electromotoric actuator, 2P, 25 Nm

SQL321B25 Electromotoric actuator, 2P, 25 Nm

SKU:SQL321B25

Low stock: 5 left

Regular price RM3,906.00
Regular price Sale price RM3,906.00
Sold out
Shipping calculated at checkout.

Control Type: On/Off

Type
Torque
Voltage AC/DC
Electromotoric actuator for operation of VKF42.. butterfly valves as shutoff and control valves in heating, ventilation and air conditioning plants. No mounting kits required.
Flange connection to EN ISO 5211.

Additional info

The actuators have built-in end switches. 1 double auxiliary switch.



Additional info

The actuators have built-in end switches. 1 double auxiliary switch.


Technical Specifications:

Torque
25 Nm
Angular rotation
90°
Power consumption
45 VA
Positioning time
11 s
Positioning signal
2-position (SPDT)
Spring return function
No
Degree of protection
IP67
Ambient temperature, operation
-20…65 °C
Medium temperature
-10…80 °C; 14…176 ºF
Ambient humidity, operation
95 % r.h.
Dimensions (W x H x D)
171 x 179 x 143 mm
Mounting position
Upright to horizontal
Operating voltage
AC 220 V
Position feedback
DC 0…10 V



Documentations:

Technical data sheet - SQL321B25
