The actuators have built-in end switches. 1 double auxiliary switch.
Technical Specifications:
1
/
of
1
Siemens
SQL361B25 Electromotoric actuator, 2P, 25 Nm
SQL361B25 Electromotoric actuator, 2P, 25 Nm
SKU:SQL361B25
Low stock: 5 left
Regular price
RM6,954.00
Regular price
Sale price
RM6,954.00
Unit price
/
per
Shipping calculated at checkout.
Control Type: Modulating (Electrical)
Couldn't load pickup availability
Electromotoric actuators 25…2650 Nm for butterfly valves VKF42..
Electromotoric actuator for operation of VKF42.. butterfly valves as shutoff and control valves in heating, ventilation and air conditioning plants. No mounting kits required.
Flange connection to EN ISO 5211.
Additional info
| Torque |
25 Nm
|
|
Angular rotation
|
90°
|
|
Power consumption
|
91 VA
|
|
Positioning time
|
39 s
|
|
Positioning signal
|
2-position (SPDT)
|
|
Spring return function
|
No
|
|
Degree of protection
|
IP67
|
|
Ambient temperature, operation
|
-20…65 °C
|
|
Medium temperature
|
-10…80 °C; 14…176 ºF
|
|
Ambient humidity, operation
|
95 % r.h.
|
|
Dimensions (W x H x D)
|
360 x 250 x 214 mm
|
|
Mounting position
|
Upright to horizontal
|
|
Operating voltage
|
AC 220 V
|
|
Position feedback
|
DC 0…10 V
|
Documentations:
